H110 Motherboard NVMe

Description

The H110 Motherboard NVMe is designed to provide a reliable foundation for desktop PCs using compatible Intel Socket 1151 processors. It supports 6th and 7th Generation Intel Core, Pentium, and Celeron processors, making it suitable for a variety of home, office, business, and everyday computing systems.

With support for DDR4 2133 memory up to 32GB and a dedicated NVMe M.2 slot, the motherboard offers a practical combination of memory capacity and modern storage connectivity. It also includes 4 SATA 6Gb/s ports for connecting additional storage devices.

For display and expansion, the motherboard provides HDMI and VGA outputs along with a PCIe x16 slot. Multiple USB ports, Realtek LAN, and 6-channel audio provide the connectivity needed for everyday peripherals and accessories.

Its Micro-ATX form factor makes the H110 Motherboard NVMe a practical choice for compact desktop builds and system upgrades.

Key Features

Support for compatible Intel 6th & 7th Gen processors
DDR4 2133 memory support up to 32GB
NVMe M.2 slot
4 × SATA 6Gb/s ports
HDMI and VGA display outputs
PCIe x16 expansion slot
Multiple USB 3.0 and USB 2.0 ports
Realtek 100M LAN
Realtek 662 6-channel audio
Compact Micro-ATX design
3 Years Warranty

Specification	Details
Model	H110 Motherboard NVMe
Chipset	Intel H110
CPU Socket	Intel Socket 1151
Processor Support	Intel 7th/6th Gen Core i7/i5/i3, Pentium & Celeron
Memory Type	DDR4
Memory Slots	2 × DDR4 DIMM
Memory Speed	2133 MHz
Maximum Memory	32GB
Expansion Slot	1 × PCIe 3.0/2.0 x16
Storage	4 × SATA 6Gb/s
M.2 Storage	1 × NVMe M.2 Slot
LAN	Realtek 100M
Audio	Realtek 662 6-Channel Audio
Video Output	HDMI, VGA
Form Factor	Micro-ATX
BIOS	AMI BIOS
Warranty	3 Years

Processor Support

Intel Socket 1151
Supports compatible Intel 7th/6th Generation Core i7 processors
Supports compatible Intel 7th/6th Generation Core i5 processors
Supports compatible Intel 7th/6th Generation Core i3 processors
Supports compatible Intel Pentium processors
Supports compatible Intel Celeron processors

Memory Support

2 × DDR4 2133 DIMM slots
Maximum supported memory: 32GB

Expansion

1 × PCIe 3.0/2.0 x16 slot

Storage

4 × SATA 6Gb/s ports
1 × NVMe M.2 slot

LAN & Audio

Realtek 100M LAN
Realtek 662 6-channel audio

USB Connectivity

4 × USB 3.0 ports
6 × USB 2.0 ports

Back Panel

1 × VGA port
1 × HDMI port
1 × RJ45 LAN port
2 × USB 3.0 ports
4 × USB 2.0 ports
3 × flexible audio jacks

Onboard Connectors

1 × USB 3.0 19-pin connector supporting 2 × USB 3.0 ports
1 × USB 2.0 connector supporting 2 × USB 2.0 ports
4 × SATA 6Gb/s ports
1 × NVMe M.2 slot
1 × 4-pin CPU_FAN/SYS_FAN connector
1 × 24-pin ATX power connector
1 × 4-pin 12V ATX power connector
1 × F_AUDIO connector
1 × F_PANEL connector

BIOS

AMI BIOS

Form Factor

Micro-ATX

Warranty

3 Years Warranty

1. Which processors are supported by the H110 Motherboard? +

The motherboard supports compatible Intel Socket 1151 6th and 7th Generation Core i7, Core i5, Core i3, Pentium, and Celeron processors.

2. How much RAM does the H110 Motherboard support? +

It supports up to 32GB of DDR4 2133 memory through two DIMM slots.

3. Does the H110 Motherboard support NVMe SSDs? +

Yes. It includes a dedicated NVMe M.2 slot for compatible NVMe SSD storage.

4. Does it support SATA hard drives and SSDs? +

Yes. The motherboard has 4 SATA 6Gb/s ports for compatible SATA storage devices.
